TEMPERATURE SENSOR (RTD. THERMOCOUPLE)

TEMPERATURE TRANSMITTER (¹æÆø¡¤ºñ¹æÆø)

FLOW & LEVEL SWITCH

HF-501
Flow Switch

HF-501 can detect Piston Cooling Oil's flow
condition and level status.
Capacitance will fluctuate with level condition.

HF-502
Combined Flow Switch & Temperature Sensor

HF-502 is integrated with Oil flow sensor and oil
temperature sensor, can detect oil flow condition
and level, also can transmit fluid state and level
control signals to outside and display oil flow
conditions as LED lights on the Junction Box.

HF-503
Flow Switch

HF-503 can detect Piston Cooling Oil's flow
condition and level status.
Vibration will fluctuate with level condition.

HF-504
Level Switch

HF-504 can detect Lubrication Oil's flow condition
and level status.
capacitance will fluctuate with level condition.


HF-505
Floating type Level Switch

INDUCTIVE CONDUCTIVITY SENSOR (ÀüÀÚ À¯µµ¼º Àüµµµµ ¼¾¼­)

Inductive Conductivity Sensor

This Inductive Conductivity Sensor(ICS-1000) is the equipment specially designed to measure the conductivity in
the solution. ICS-1000 sensor measures conductivity of seawater flowed through the certain pipe. The result of
measurement(Conductivity and Temperature) is indicated on the indicator(ICS-1000M). The indicator outputs
conductivity and temperature as the Current Loop of 4mA-20mA.
Data Communication is using RS485(NMEA0183) between ICS-1000 sensor and ICS-1000M indicator.

Specification

Measurement Range : 0mS/cm ~ 100mS/cm

Measurement Error : ¡Â 5% Max of measured value including Temperature Compensation

Current Output Error : ¡Â 2% of full measured range

Repeatability : ¡Â 1% of measurable full scale

Arrival Time for Target Temp: ¡Â 10 minutes

Output Signal : Current loop 4mA ~ 20mA (Default) / RS485 Communication (Option)

Power Supply : DC24V ( 18V ~ 30V)

Power Consumption : 5W Max

Operating Temperature : -10¡ÆC ~ 70¡ÆC

Operating Pressure range : 10 bar Max.

Ingress Protection : IP65

Electromagnetic Compatibility : Satisfied EN61326 rule

THERMOMETER & PRESSURE GAUGE
